ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 10 Getting started with your ZyWAN This section helps a first-tim

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 11 Software requirements of configuration computer The computer u

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 12 Ports, LEDs and connectors The front panel of the ZyWAN contai

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 13 LED indicators The ZyWAN has three LED lights which indicate t

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 14 Power connection The ZyWAN can be powered from 10-30 VDC. Powe

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 15 Serial connections Pin assignments for the serial ports are sh

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 16 RS-485 / RS-422 wiring diagrams When connecting RS-485 or RS-4

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 17 Installing a SIM card (GPRS/IDEN) The ZyWAN for a GPRS or IDEN

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 18 Understanding Interfaces The ZyWAN contains four possible IP n

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 19 Initial configuration with a single PC The ZyWAN typically com

ZyWAN User Manual ISO 9001 FM12961 Definitions Eurotech is the trading name for Eurotech Ltd. Disclaimer The information in this manual has been ca

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 20 Set up computer’s network The PC must be set up to obtain its

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 21 3 Record the existing settings, then make the changes to obta

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 22 Browse ZyWAN configuration page To browse the ZyWAN configurat

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 23 Initial configuration over a network An alternate way to start

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 24 Apply power Connect the power supply to a wall outlet and to t

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 25 4 Make the following settings for the serial communication, t

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 26 An example is shown below of setting the network address to 10

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 27 Troubleshooting connection problems If the Web configuration p

ZyWAN User Manual Getting started with your ZyWAN © 2007 Eurotech Ltd Issue B 28 If using the ZyWAN as a DHCP Server to the PC: • Make sure th

ZyWAN User Manual Configuring the ZyWAN © 2007 Eurotech Ltd Issue B 29 Configuring the ZyWAN Configuration of the ZyWAN is done using a Web bro
